59160001-MCSC Edition 06 08.05.2013 / Bak page 24/34
E 0-9,A-F 0-9 0-9
Control unit error in software-module 0-15
F 0-9,A-F 0-9 0-9
Control unit error in software-module 16-31
Digit 2 = Module code modulo 16 (hex), see source code 'pro-
ject.h', xxxx_MODULE_ID
Digits 3+4 = decimal error code 00..99, see source code 'ret-
val.h'
E 1 * *
MAIN_
E 2 * *
TIMER_
E 3 * *
WATCHDOG_
E 4 * *
CAN_
E 5 * *
CANCOM_
E 6 * *
EEDATA_
E 7 * *
FLASHCHK_
E 8 * *
CONTROL_
E 9 * *
CONTROL_REF_
E A * *
MOTOR_
E b * *
LEDCTRL_
E C * *
SWITCH_
E d * *
MMISLAVE_KEY_
E E * *
MMISLAVE_LED_
E F * *
LCD_
F 0 * *
USER_
F 1 * *
ADCINT_
F 2 * *
DIPSW_
F 3 * *
CRITVAR_
* * 0 0
OK no error
* * 0 1
ERR general error
* * 0 2
ERR_ILLEGAL_CASE illegal case state in graph
* * 0 3
ERR_ILLEGAL_ACT illegal action state in graph
* * 0 4
E_NULLPOINTER a function has received a null point-
er where not applicable
* * 0 5
E_EXECFLAGNOTFALSE execution flag was not false in
graph
* * 0 6
E_WDFAIL watchdog test failed (watchdog did
not reset the CPU correctly)
* * 0 7
E_WDRESET an unintended watchdog reset has
occurred
* * 0 8
E_FLASHCHK_FAIL the FLASH CRC check failed
* * 1 0
E_TICKOV Ticker tasks overflow (tasks too
slow)
* * 1 1
E_SLOWTICKOV Slow Ticker tasks overflow (tasks
too slow)
