Mach M3
Dr. Mach
Lamps and Engineering
3.2 Lamp housing, dispersing lens
and support system
The OT-lamp MACH M3 has a high-quality surface,
which can be cleaned with conventional cleaning
agents.
The lens system 2 is made of a high-quality plastic.
Pay attention to the following during cleaning:
- Never wipe over the lens system 2 with a dry
cloth (always clean with a wet cloth).
- Only use disinfectants with less than 20%
alcohol.
Wipe the lens system 2 after cleaning with an
antistatic, non-fluffy cloth.
2
Alc. ≤ 20 %
4. Maintenance
MACH lamps are supplied with brakes on the suspension fixture and on the lamp housing. Adjust these
brakes as necessary after installation.
If the lamp is difficult to move or if it does not stay in position, the brake forces should be adjusted.
The lamps and suspension fixtures have been designed and built, so that regular maintenance intervals
are not necessary.
In order to keep the system easy running throughout its life span, we recommend that the hinges should
be greased once a year with acid-free grease.
When adjusting the brakes or the hinges at the ceiling attachment please consult the mounting
instructions “Ceiling attachment with heavy central axis” or “Ceiling / wall attachment”.
4.1 Adjustments at the lamp head
The fine adjustment for handling the lamps can be
carried out at points 2 and 3.
To adjust the brakes use a screw driver with
appropriate size.
If you cannot adjust the brakes at points 2 and 3
anymore as tight as necessary, you will have to
replace them.
Remark:
In order to adjust brake 2, the upper housing
part must be removed.
Upper housing part
3
4
59200001 Edition 06 28.11.2002 / Bak page 12/22
