9. Spare parts list
Item Qty. Name EDVNO Remarks
1 1 Lower housing part for lamp without camera 20012204
2 1 Lower housing part for lamp with camera 20012205
3 1 Upper housing part 20011201
4 1 Turn-lock fastener 20088209
5 1 Locking washer 20088201
6 1 Locking sheet metal 20089208
7 1 Adjusting sheet metal 0,5 20088205 alternative
8 1 Adjusting sheet metal 1,0 20088206 alternative
9 1 Adjusting sheet metal 1,5 20088207 alternative
10 1 Adjusting sheet metal 2,0 20088208 alternative
11 1 Sterilisable handle 21150002
1 Coupling DF for sterilisable handle 20220001 DF-model
1 Coupling F for sterilisable handle 20220002 F-model
12
1 Coupling DF-M for sterilisable handle 20220003 DF-M-model
13 1 Cardanic suspension
14 1 Brake screw M12
15 1 Keypad OPLT DF/H-model
16 1 Keypad holder 21115003
17 1 Sealing cord RAL 5018 20088211
18 3 Reflector unit DF 20060001 DF-model
19 3 Reflector unit F 20060002
20 12 Fixing screw M3x16 DIN 912
with washer
65052012
21 3 Halogen bulb 22,8V 50W 67100201
22 3 Socket for halogen bulb 67320007
23 3 Knurled screw 28060213
24 2 Fuse 0,63 AT 5x20 67370003
25 1 Dimmer module OPDIM V3.0 24080001 Check version and
number
26 1 PCB board OPDX-M3 V0.10 67250101 Check version and
number
27 1 Gear motor 67030105
28 3 Filter disk 23250201
29 12 Spring holder 20086001
30 3 Retaining ring
31 18 Fixing screw M3x10 DIN 912
with lock washer
65052078
32 18 Washer 65512017
33 3 Dispersing lens 21200201
34 1 Acrylic glass box for transformer 300VA 67610101 Accessory
Bowden control
35 1
Primary shaft 20080201
36 1
Screw M3x6:Ni ULF 65052002
37 1
Screw M3x6 DIN 912,
turned-to-size head
28082203
38 1
Tension bolt 20080206
39 6
Cable holder 67900006
40 1
Round stranded rope 20080202
59200001 Edition 06 28.11.2002 / Bak page 19/22
