2.6 Positioning
Use the sterile handle 2 or the handle rails 1 to
position the lamps.
Use the handle rail to position the lights before the
operation.
Use the sterile handle for positioning during the
operation. This handle can be removed for
sterilization.
1
1
The working distance of the F-lamps is 0,7m to
1,4m.
The working distance of the DF-lamps is 0,6m to
1,5m.
The handle is supplied with a detectable mechanical
catching. When the handle catches in this position,
the lamp is optimally set for a working distance of 1
meter.
2
1,4m
(1,5m)
1m
0,7m
(0,6m)
0
Two or more lamps can be used for an intensive
illumination of large operation fields.
It is also possible to illuminate two operation fields
simultaneously.
59200001 Edition 06 28.11.2002 / Bak page 9/22
