DR 6.25 TOW-BEHIND User Manual

CONTACT US AT www.DRpower.com 21
Storage
It is quick and easy to partially disassemble the machine to take up less space
when stored.
Tools Needed:
 7/16" Wrench
1. Loosen the Chain Link using a 7/16" Wrench and remove the Chain Link
from the Frame (Figure 43).
2. Pull the Hair Pin from the Swivel Frame Shaft and remove the Swivel Frame
from the Machine (Figure 44).
Spring
Figure 43
Chain
Link
Inner Hole
Outer Hole
Pivot
Bracket
Figure 44
Hair Pin
Swivel Frame

DR 6.25 TOW-BEHIND Specifications

General

Brand	DR
Model	6.25 TOW-BEHIND
Category	Lawn Mower
Language	English
