Chapter 6: Parts Lists and Schematic Diagrams
Parts List – Drive Assembly
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 34123 Spindle, LH Thread
2 31098 Can, Anti-Wrap
3 31097 Plate, Line Spacer, D Bore
4 31102 Cord Pack, 25", 12 Pcs
5 31101 Mow Ball, Hex Bolt
6 34126 Bolt, 3/8-16 X 1", Gr5 ZP, High Head,
Left Hand Thread
7 31099 Spacer, .680" X .984" X .310", ZP
8 31117 Screw, HWH, 1/4-20 X 3/4", Taptite
9 32200 Pulley, 3.5" ED, A-Profile V-Belt, .67"
Shaft
10 33438 Idler Bracket
11 14409 Pulley, V-Belt, 2.625" O.D., Idler
12 34143 Pulley, Drive, A V-Belt, 7/8" Shaft
13 33772 Belt, Double V, Aa62
14 19351 Spring, Extension
15 11116 Pulley, Idler, Aa, V-Belt, 4" OD, 1/2" ID
16 11155 Bolt, HHCS 3/8-24 X .75", Gr.2, ZP
Ref# Part# Description
17 33333 Nut, Nylon Lock, Flanged, 3/8-16
18 33775 Pivot, Bushing
19 11238 Washer, Flat, 1/4"
20 26535 Bolt, Shoulder, 1/2" X .75" L
21 34158 Engine, 6.25tq, 190cc, Briggs, MS, W/
Labels
22 13758 Label, Check Oil, 2.75" x .63"
23 33348 Bolt, Hex, Flange, 3/8-16 X 2.5"
24 11914 Key, Sq, 3/16" X 1"
25 34150 Bushing, 3/8" ID, 1/2" OD, .75" L
26 31104 Guard, Trimmer
27 13649 Label, Danger, Blade
28 11241 Washer, Flat, 5/16" USS, ZP
29 34168 Bolt, HCS, 5/16-18 X 3/4", Left Hand, ZP
30 34407 Bolt, Hex, Flange, 3/8-16 X 1.5", Gr5, ZP
31 28990 Bolt, Hex, Flange, Tri Lobe, 3/8-16 X 1",
Gr5 ZP
