Chapter 6: Parts Lists and Schematic Diagrams
Parts List – PRO-16 Battery Lawn Mower
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 41423 2.5 Ah Battery
2 42046 Blade Bolt
3 42047 Blade
4 42048 Fan
5 42049 S1-62V Power System Set
6 42050 6" Wheel Cover
7 42051 Non-Metal Insert Flange Nut
8 42052 6" Wheel
9 42053 Wave Washer
10 42054 Square Neck Head Bolt
11 42055 Front Wheel Axle Top Support
12 42056 Front Wheel Axle Lower Support
13 42057 Front Wheel Axle
14 42058 Weighting Spring
15 42059 Hexagon Flange Locknut
16 42060 16" Steel Deck
17 42061 Front Face
18 42062 Hexalobular Socket Pan Head Tapping
Screws
19 42063 Lifting Handle
20 42064 Connecting Rod
21 41790 Hexagon Locknut
22 42066 Hexagon Socket Button-Headed Screw
23 42067 Gear Plate
24 42068 Mulching Plug
25 42069 Trailing Shield
26 42070 Pressing Plate
27 42071 Cross Recessed Pan Head Screw
28 42072 Hexagon Flange Locknut
29 42073 7" Wheel Cover
30 42074 7" Wheel
31 42075 Rear Wheel Axle Lower Support
32 42076 Rear Wheel Axle Top Support
33 42077 Rear Wheel Axle
34 42078 Right Height Adjustment Handle
35 42079 Left Height Adjustment Handle
36 42080 Gear Set
37 42081 Bobes Recessed Pan Head Tapping
Screw
38 42082 Cross Recessed Countersunk Head
Tapping Screws
39 42083 Insulation Sleeve
40 42084 Insulation Sleeve
41 42085 Rotary Knob
42 42086 Lower Handlebar
43 42087 Lower Handlebar Right Bracket
44 42088 Lower Handlebar Left Bracket
Ref# Part# Description
45 42089 Hexagon Flange Head Bolt
46 42090 Hexagon Nut
47 42091 Wire Clamp
48 42092 Rear Cover
49 42093 Square Neck Head Bolt
50 42094 Dust Excluder
51 42095 Cap Nut
52 41800 Bobes Recessed Pan Head Tapping
Screw
53 42097 E-Shaped Elastic Ring-Shield
54 42098 Rear Cover Torsional Spring
55 42099 Rear Cover Bolt
56 42100 40L Grass Catcher
57 42101 Bobes Recessed Pan Head Tapping
Screw
58 42102 Grass Catcher Bracket
59 42103 Gasket
60 42104 40L Grass Catcher Cover
61 42105 Grass Catcher Handle
62 42106 Wind Door Cover
63 42107 Wrench
64 42108 Round Pin
65 42109 Nut Bracket
66 42110 Square Neck Head Bolt
67 42111 Flat Washer
68 42112 Quick-Assembly Bolt
69 42113 Switch Box Cover
70 42114 Switch Box
71 42115 Press Button
72 42116 Switch Spring
73 42117 Elastic Piece
74 42118 Trigger
75 42119 Rocker Switch
76 42120 The Cable Pressing Plate
77 42121 Headless Power Cord
78 42122 Switch Cover
79 42123 Trigger Seat
80 42124 Reset Torsional Spring
81 42125 Trigger Seat Cover
82 42126 Upper Handlebar
83 42127 Rubber Hose
84 42128 S.S. Wire Trigger
85 42129 Flat Washer
Not Shown
41421 2.5 Ah Charger
