28 DR
®
TOW-BEHIND FIELD and BRUSH MOWER
Chapter 6: Parts Lists and Schematic Diagrams
Parts List – Frame Assembly
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 354941 Brace, Sway
2 362891 Bushing, Sway Brace
3 111701 Screw, 10-32 X 1/2, Type F (Pro & Pro XL)
4 371391 Support, Wheels, Brush, Right, w/Labels
5 371381 Support, Wheels, Brush, Left, w/Labels
6 354981 Caster, Front, Brush
7 354821 Wheel, 13 X 5-6″, Lug Tread
8 354811 Wheel, 11 X 4-5″, Flat Free, Smooth Trd
9 371201 Guard, Push Bar
10 354951 Bracket, Offset
11 354961 Bar, Tow
12 354971 Extension, Tow Bar
13 234991 Washer, 0.53″ ID X 1.06″ OD X 0.095″, Zp
14 363171 Chain, Welded, 1/4″ Grade 30 Proof
15 363151 Bracket, Chain Guard
16 363161 Rod, Chain Guard
17 373831 Bar, Push
18 101891 Grease Fitting, Zerk, 1/4-28 Straight
19 343241 Bolt, HCS, 3/4-10 X 7″, GR5 ZP
Ref# Part# Description
20 365721 Bolt, Hex, Flange, 1/2-13 X 3.5″, GR5
21 365731 Bolt, Hex, Flange, 1/2-13 X 4.5″, GR8 ZP
22 345111 Bolt, Hex, Flange, 1/2-13 X 3″, GR5 ZP
23 352811 Bolt, Hex, Flange, TL, 3/8-16 X 3/4″
24 333381 Nut, Nylon Lock, Flanged, 3/4-10
25 333351 Nut, Nylon Lock, Flanged, 1/2-13
26 186551 Pin, Cotter, 3/16 X 2″
27 187371 Pin, Clevis, 1/2 X 4.5″ L, ZP
28 255491 Pin, Clevis, 1/2 X 2-1/2″, TRT
29 160031 Pin, Hitch Clip, 1/2″-9/16″
30 371251 Label, Crank Direction
31 365821 Label, Height Adjust, Left
32 365811 Label, Height Adjust, Right
33 373831 Push Bar (Pro & Pro XL)
362721 Brace, Rear (Premier)
34 363111 Cable Clamp, 3/4″ Nylon (Pro &Pro XL)
35 371401 Label, QR Code
