DR PRO 44T - Setting Up the DR TOW-BEHIND FIELD and BRUSH MOWER; Controls and Features Overview (Pro;Pro-XL Models)

6 DR
®
TOW-BEHIND FIELD and BRUSH MOWER
Figure 2
Hand Crank
Height
Adjusters
Briggs and Stratton 20 HP
Engine
(16.5 HP Engine will look
different than shown)
Tow Bar Locking Pin
Battery
Chain Debris
Guard
Tow Bar
Tow Hitch
Oil Drain
Hose
Fuel Tank
Fuel Fill
Throttle
Control
Electric Start
Key Switch
Oil Fill
Cap/Dipstick
Blade Engage
Switch
Fuel Shutoff
Valve
Left Side
Oil Filter
Muffler
Fuel Filter
Chapter 2: Setting Up the DR TOW-BEHIND FIELD and BRUSH MOWER
It may be helpful to familiarize yourself with the controls and features of your DR TOW-BEHIND FIELD and BRUSH MOWER by
reviewing Figure 2 before beginning these procedures. If you have any questions at all, please feel free to contact us at
www.DRpower.com.
DR TOW-BEHIND FIELD and BRUSH MOWER Controls and Features (Pro and Pro-XL Models)
NOTE: The model shown in Figure 1 may look slightly different from your machine.
