28 DR
®
WIDE-CUT LAWN MOWER
Parts List - Drive Assembly
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 10000041169 Spring, Torsion, Discharge Guard
2 A0000210405 Spring, Extension, Blade Brake
3 395531 Bushing, Idler, Blade Brake
4 395541 Arm, Idler, Blade Brake (SP30)
A0000166771 Arm, Idler, Blade Brake (SP26)
5 395571 Pulley, Engine
6 A0000296259 Frame
7 A0000296276 Engine, DR, 225cc, ES w/labels
(SP30)
A0000296277 Engine, DR, 225cc, MS w/labels
(SP30)
A0000296278 Engine, DR, 200cc, ES w/labels
(SP26)
A0000296281 Engine, DR, 200cc, MS w/labels
(SP26)
8 395661 Pin, Pivot, Rear Discharge Guard
9 395771 Guard, Trailing
10 A0000296270 Guard, Rear Flap w/labels
11 396311 Spring, Ext, 1.25" OD, 6.5" L, .162"
Wire
12 10000040710 Bracket, Anti Rotation, Transmission
13 A0000215154 Guide-Belt-Pin-Engine Pulley
14 131191 Battery, 5.6 Ah, 12V (ES Only)
15 325141 Pad, Secondary Brake, Beaver Blade
16 350471 Pulley, Flat Idler, 1.75" X .75"
17 A0000020863 Clamp, Battery, 5Ah (ES Only)
18 377381 Bushing, Spacer
19 395651 Belt, AP35, Blade Brake (SP30)
396151 Belt, AP31, Blade Brake (SP26)
20 395241 Belt, 3L320, Self Propel
21 395351 Wheel, Rear, 10" X 3", Square Tread
22 395471 Pinion, Rear Axle
23 395481 Gear, Spur, Drive
24 395461 Housing, Bearing, Rear Axle
25 391261 Transmission & Axle
26 396191 Bearing, Flanged, 1/2" ID, 1-3/8"
OD
27 395501 Plate, Support, Bearing
28 396321 Spring, Ext, 0.5" OD, 5.25" L, 0.08"
Wire
Ref# Part# Description
29 395441 Axle, Rear
30 395551 Handle, Height Adjust
31 396181 Knob, Tapered, Plastic
32 395431 Cover, Wheel
33 A0000296268 Linkage, Height Adjust w/labels
(SP30)
A0000296269 Linkage, Height Adjust w/labels
(SP26)
34 352811 Bolt, Hex, Flange, TL, 3/8-16 X 3/4"
35 289901 Screw, Unsltd Trilobe, 3/8-16 X 1"
36 111731 Screw-5/16-18 X 1/2 Tri
37 365211 Bolt, Hex Flange, 1/4-20 X 5/8", ZP
38 385961 Bolt, Hex, Flange, 3/8-16 X 1-3/4",
GR5
39 390861 Bolt, Hex, Flange, 3/8-16 X 2-1/4",
GR8
40 333331 Nut, Nylon Lock, Flanged, 3/8-16
41 189751 Ring, Retaining, .468" ID,
External
42 333311 Nut, Nylon Lock, Flanged, 1/4-20
43 118731 Nut, Nylon Lock, 10-24
44 111551 Bolt, HCS, 3/8-24 X 3/4", GR5, ZP
45 A0000162518 Screw, Plastic Thread Forming, 8-16
X 1"
46 A0000213836 Label, Warning, General
47 A0000212734 Label, One Touch Height
Adjustment
48 101891 Zerk, Grease, 1/4-28, Straight
49 0K0982 Ring, Snap, 1/2", Type E
50 323441 Screw, 10-24 X 0.75", Fillister
51 276761 Pin, Cotter, 3/32" X 1/2", ZP
52 A0000191699 Label, Engine Branding, RV225
(SP30)
A0000191697 Label, Engine, RV200 (SP26)
53 A0000191696 Label, Engine Torque, RV225 (SP30)
54 343251 Bolt, Hex, Flange, 1/4-20 X 1"
Not Shown:
137581 Label, Warning, Check Oil
To Next Page
