DR SP26 - Chapter 2: Setting Up the DR WIDE-CUT LAWN MOWER; Controls and Features Overview

8 DR
®
WIDE-CUT LAWN MOWER
Upper and Lower
Handlebar
Blade Engage
Bail Ba
r
Figure 1
Traction
Lever
Oil
Fill/Dipstic
k
Bagger
A
ssembly
Cutting Height
Lever
A
ir Filte
r
Fuel Tank
Cap
Pull Start
Handle
Ball Bearing
Wheels
Cast Aluminum
Deck
Key Switch
Discharge
Guard
Battery
(Electric Start
Models)
Two Step
Lever
Maintenance Meter
(Optional Accessory)
Side Discharge
Cover
Handlebar
A
djust Lever
Discharge
Deflector
Mulching
Plug
Chapter 2: Setting Up the DR WIDE-CUT LAWN MOWER
It may be helpful to familiarize yourself with the controls and features of your DR WIDE-CUT LAWN MOWER as shown in Figure 1
before beginning these procedures.
If you have any questions at all, please feel free to contact us at www.DRpower.com.
DR WIDE-CUT LAWN MOWER Controls and Features
