30 DR
®
WIDE-CUT LAWN MOWER
Parts List - Handlebar Assembly
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 395601 Lever, Handlebar Adjust
2 A0000296271 Bracket, Handlebar Adjust w/labels
3 395591 Pin, Wire Form, Handlebar Adjust
4 10000041178 Spring, Torsion, Handlebar Adjust
5 395691 Handlebar, Lower
6 395681 Handlebar, Upper
7 395751 Bracket, Switch
8 395781 Cable, Traction Drive
9 395791 Cable, Blade Engage
10 A0000296274 Console, Handlebar w/labels (SP26)
A0000296275 Console, Handlebar w/labels (SP30)
11 151311 Plug, Panel, 2.0" X 1.4"
12 222231 Switch, Snap in, E/S
165201 Switch, Snap in, M/S
13 396221 Bail Bar, Blade Engage
14 395721 Lever, Self Propel Drive
15 395741 Lever, 2 Step
16 365211 Bolt, Hex Flange, 1/4-20 X 5/8", ZP
17 385961 Bolt, Hex Flange, 3/8-16 X 1-3/4",
GR5
18 343251 Bolt, Hex, Flange, 1/4-20 X 1"
Ref# Part# Description
19 333331 Nut, Nylon Lock, Flanged, 3/8-16
20 333311 Nut, Nylon Lock, Flanged, 1/4-20
21 A0000052226 Bolt, Shoulder, 1/2" OD X 1-1/4" X
3/8-16 Thread
22 A0000052276 Pin, Clevis, 1/4" X 2-1/8" ZP
23 A0000203118 Label, Handle Adjust
24 A0000162520 Screw, Plastic Thread Forming, 8-16
X 1/2"
25 A0000069640 Wire Harness, E/S
A0000069641 Wire Harness, M/S
26 276751 Pin, Clevis, 1/4" X 1-1/8"
27 A0000163050 Spring, Torsion, 2-Step Lever
28 276761 Pin, Cotter, 3/32" X 1/2"
29 A0000191688 Label, Console (SP30)
A0000191690 Label, Console (SP26)
Not Shown:
396231 Frame, Grass Bag
396241 Bag, Fabric
To Next Page
