36 DR
®
TRIMMER/MOWER
Chapter 6: Parts Lists, Schematic Diagrams And Warranty
Parts List - Handlebar Assembly - SPRINT
and PRO
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 111581 Bolt, HCS, 5/16-18 X 1"
2 110761 Nut, Nylon Lock, 5/16-18
3 112381 Washer, Flat, 1/4", USS
4 110731 Nut, Nylon Lock, 1/4-20
5 143841 Stud, Pivot
6 143651 Bail Bar, Non Self-Propelled
7 112141 Cable Tie, 7-1/2" L
8 143981 Cable, Clutch
9 143971 Cable, Throttle, Reverse Throw
10 114561 Bolt, HHCS, 1/4-20 X 2.0", Gr. 2, ZP
11 123361 Bolt, HHCS, 5/16-18 X 1.25", Gr. 5, ZP
12 113081 Start Switch Assembly, ES
13 143671 Stop, Bail Bar
14 112481 Bracket, Clutch Cable
15 101451 Bolt, HHCS, 1/4-20 X 1.5"
16 112371 Washer, Flat, 10-24, USS
17 144641 Bolt, 5/16-18 X 3.0"
18 291991 Bracket, Key Switch, W/ Label
Ref# Part# Description
19 143661 Knob, Handlebar, 5/16-18
20 179191 Handlebar, Upper, Black, W/ Label
21 143931 Spring, C, .545" O.D. X .55" Wire
22 143731 Adjuster, Handlebar, Outside
23 191351 Adjuster, Handlebar, Inside
24 174561 Handlebar, Lower, Black
25 143881 Lever, PTA
®
26 143901 Knob, PTA
®
Lever
27 144001 Cable, PTA
®
28 143891 Bracket, PTA
®
Lever
29 165331 Grip, Handlebar, Foam, Non Self-
Propelled
30 188241 Wire Harness, W/ Adapter
31 240641 Label, Trimmer, Patent number
32 153081 Label, Bail Bar
33 214661 O-Ring, .375"OD, .25"ID, .0625"T
34 193201 Label, Start Key Bracket
35 145801 Handlebar Adjuster Assembly
