DR SPRINT Safety & Operating Instructions

CONTACT US AT www.DRpower.com 7
Tape
Figure 2
Specifications
MECHANICAL SPECIFICATIONS
Sprint Pro Pro-XL Self-Propelled
Engine
See Engine Owners Manual for
details
See Engine Owners Manual
for details
See Engine Owners Manual for
details
Wheels
14" Resin 16" Resin 14" Resin
Frame
Steel Steel Steel
Cutting Width
20" 20" 20"
Cutting Height
1-1/2" to 4" 1-1/2" to 4" 1-1/2" to 5"
Machine Width
23" 23" 22"
Machine Weight
68 lbs. Manual Start, 75 lbs.
Electric Start
70 lbs. Manual Start, 77 lbs.
Electric Start
90 lbs. Electric Start
Unpacking the DR TRIMMER/MOWER
Tools Needed:
 Utility Knife
 5/8" Wrench
 Wire Cutters
1. Position the Shipping Box at floor level in a clean flat area with the text on
the side of the Box right side up (Figure 2).
2. With a Utility Knife, cut the Tape that secures the Box Flaps at both ends and
along the center.
Parts Supplied in Box (Figure 3):
 DR TRIMMER/MOWER
 Trimmer Wheels
 Product Package (plastic bag with owner's manual, engine manual, head
locking tool, and other product information)
 Trimmer Cord Pack
 Two Keys, for electric-starting models (located just below the Bail Bar
Spring of the Trimmer)
Compare the contents of the Shipping Box with the “Parts Supplied” list above.
If you have any questions please contact us at www.DRpower.com or call 1-800-
DR-OWNER (376-9637) for assistance.
3. Remove the Product Package and Trimmer Cord Pack from the Shipping
Box.
Figure 3
Product
Package
Trimmer
Cord
Pac
k
DR
Trimmer/
Mower
Keys
Whee
l
Bail Bar
Spring
Whee
l
Stabilize the shipping box at floor level in a clean flat area before attempting to unpack the Trimmer/Mower. For your safety we
recommend you have two people for the following procedures.
