40 DR
®
TRIMMER/MOWER
Parts List - Handlebar Assembly - SELF- PROPELLED
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 111581 Bolt, HCS, 5/16-18 X 1"
2 110761 Nut, Nylon Lock, 5/16-18
3 112381 Washer, Flat, 1/4", USS
5 110731 Nut, Nylon Lock, 1/4-20
7 214661 O-Ring, .375"OD, .25"ID, .0625"T
8 190011 Cable, Clutch, Self-Propelled
9 143971 Cable, Throttle, Reverse Throw
10 114561 Bolt, HHCS, 1/4-20 X 2.0", Gr. 2, ZP
11 123361 Bolt, HHCS, 5/16-18 X 1.25", Gr. 5, ZP
12 113081 Start Switch Assembly, ES
13 190471 Grip, Handlebar Foam, Self Propelled
14 143671 Stop, Bail Bar
15 143681 Bracket, Clutch Cable
16 189721 Bail Bar, Self Propelled
17 101451 Bolt, HHCS, 1/4-20 X 1.5"
18 112371 Washer, Flat, 10-24, USS
Ref# Part# Description
19 144641 Bolt, 5/16-18 X 3.0"
20 291991 Bracket, Key Switch, W/ Label
21 143661 Knob, Handlebar, 5/16-18
22 179191 Handlebar, Upper, Black, W/ Label
23 143931 Spring, C, .545" OD X .55" Wire
24 143731 Adjuster, Handlebar, Outside
25 191351 Adjuster, Handlebar, Inside
26 174561 Handlebar, Lower, Black
27 188241 Wire Harness, W/ Adapter
28 240641 Label, Trimmer, Patent Number
29 153081 Label, Bail Bar
30 145801 Handlebar Adjuster Assembly
31 193201 Label, Start Key Bracket
32 112141 Cable Tie, 7-1/2" L
33 286341 Cable, Transmission, TR3 Self-Propelled,
34 179651 Lever, Drive, Engagement
