42 DR
®
TRIMMER/MOWER
Parts List - Axle Assembly - SELF- PROPELLED
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 111581 Bolt, HCS, 5/16-18 X 1"
2 110761 Nut, Nylon Lock, 5/16-18
3 112381 Washer, Flat, 1/4", USS
4 152501 Bolt, HCS, 1/4-20 x 3/4", Flanged, ZP
5 110731 Nut, Nylon Lock, 1/4-20
6 101811 Washer, Lock, 1/4", Split, ZP
7 112371 Washer, Flat, 10-24, USS
8 282871 Shield, Inner, Lower, Self-Propelled TR3
9 143821 Guide, Belt Engine Pulley
10 143751 Washer, .505" ID X 1.0" OD
11 213181 Key, Woodruff, 1/8" X 1/2"
12 111681 Set Screw, 1/4-20 X 1/4", Cup Point
13 287231 Screw, 10-32 X 1", Thread Forming Hex
14 189751 Retaining Ring, .468" ID
15 118731 Nut, Nylon Lock, 10-24
Ref# Part# Description
16 175521 Bolt, Eye, 10-24 X .50"
17 290101 Spring, Ext, .312" X .0348" X 1.0", ZP
18 152331 Nut, Nylon Lock, 7/16-20, Low Profile
19 292031 Wheel, Plastic, 14", W/ Clutch Assy,
Right
20 292021 Wheel, Plastic, 14", W/ Clutch Assy, Left
21 179581 Belt, 3/8" X 20"
22 283241 Chain, #35, 50 Link And Ml
23 283211 Transmission, Self-Propelled, TR3
24 282831 Plate, Axle Mounting, Right
25 282851 Plate, Axle Mounting, Left
26 179551 Bearing, W/ Flange
27 193821 Sprocket, 40 Tooth
28 193811 Sprocket, 10 Tooth
29 175601 Pulley, Transmission Drive, 2.75"
30 282861 Axle, Self-Propelled, TR3
To Next Page
