44 DR
®
TRIMMER/MOWER
Parts List - Mow Ball
®
Assembly - All Models
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 147181 Bearing Housing Assy
2 252291 Head Assy, Complete, 6 Plate, Sprint and
Pro models
292041 Head Assy, Complete, 8 Plate, Pro-XL
Self-Propelled models
3 144701 Bolt, HCS, 5/16-18 X 3/4", Serrated
Flange
4 143991 Spring, Brake Return
5 143921 Bearing, W/ Snap Ring
6 114781 Screw, 10-24 X 5/8", Philips Pan Head
7 112371 Washer, Flat, 10-24, USS
8 121521 Washer, .380" ID X .750 OD, Nylatron
9 143511 Arm, Brake
10 213081 Bolt, 5/16-18 X 2.75", Flat Head
Ref# Part# Description
11 143501 Bearing Plate, Lower
12 143531 Pulley, V-Belt, 3.50"
13 143541 Plate, Backup
14 143551 Standoff, Line Plate, 6 Plate, Sprint and
Pro models
15 235151 Plate, Line Spacer
16 144101 Support, Mow-Ball
®
, Nylon
17 144631 Bolt, Mow-Ball
®
, 6 Plate, Sprint and Pro
models
18 282901 Bolt, Mow-Ball
®
, 8 Plate, Pro-XL Self-
propelled models
19 283291 Standoff, Line Plate, 8 Plate, Pro-XL Self-
propelled models
20 143491 Bearing Plate, Upper
Not Illustrated:
152361 Tool, Head Locking
