SECTION VI – PARTS LIST & ASSEMBLY DRAWINGS
TLC18-CHP PARTS LIST
ITEM # PART # QTY DESCRIPTION
1 030-0325 1 18HP B&S VANGUARD ENGINE
2 090-0462 10 5/16-18 X 3/4" CARRIAGE BOLT
3 913-0375 1 CHIPPER HOPPER
4 090-0233 25 5/16 USS FLATWASHER
5 090-0460 37 5/16-18 NYLOCK NUT
6 913-0232 1 CHIPPER BASIC MACHINE
7 913-0284 1 DISCHARGE CHUTE ASSEMBLY
8 090-0066 6 5/16-18 X 3/4" HHCS
9 913-0252 1 SWIVEL BASE
10 913-0253 1 SWIVEL TOP WELDMENT
11 913-0258 1 DEFLECTOR
12 500-0051 1 LOCKING KNOB
13 090-0088 16 5/16-18 X 1" HHCS
14 090-0394 3 5/16 SPLIT LOCK WASHER
15 913-0224 1 BELT GUARD
16 913-0327 1 L BRACKET - BASIC MACHINE
17 090-0438 3 5/16-18 J NUT
18 030-0193 2 BELT
19 703-0424 2 1/4 SQ. X 2" KEY
20 030-0237 1 BUSHING
21 030-0211 1 2 GROOVE SHEAVE
22 913-0328 1 Z BRACKET WLDMNT - BELT GUARD
23 911-0214 1 L BRACKET - BELT GUARD
24 090-0633 1 3/8-24 X 1 1/2" HHCS GR8
25 704-0106 1 CLUTCH WASHER
26 911-0249 1 CLUTCH SPACER
27 911-0236 1 CLUTCH
28 090-0072 4 5/16-18 X 2"
29 704-0119 1 SAFETY SWITCH
30 702-0040 2 WHEEL AND TIRE
31 911-0025 2 FENDER WELDMENT
32 090-0453 4 1/4-20 WHIZ NUT
33 090-0111 4 3/8-16 X 1 1/4" HHCS
34 090-0461 10 3/8-16 NYLOCK NUT
35 911-0212 2 AXLE BRACKET
36 911-0229 4 3/8-16 X 3" U-BOLT
37 913-0217 1 BATTERY HOLD DOWN
38 090-0128 4 1/2-13 X 1 1/4" HHCS
39 911-0219 2 HITCH ARM
40 913-0266 1 POSITIVE BATTERY CABLE
41 913-0086 1 BATTERY
42 090-0050 4 1/2-13 GRIPCO LOCKNUT
