Description
4
en
2.2 Typographical conventions
This symbol indicates information which facilitates the use of the
product.
3 Description
3.1 Product overview
1 Breath-alcohol-analyzer
2 button (switch instrument on/off; confirm inputs)
3 button (open menu; set value)
4 LEDs
5 Mouthpiece receptacle (configurable: right or left)
6 Display
7 button (set value)
8 USB connection (Important: Not for charging the device, for
Service only)
9 Wrist strap
10 Battery compartment cover
11 Battery
12 Pull strap for battery replacement
13 Loudspeaker (Important: Not reset button)
14 Mouthpiece
3.2 Intended use
The Dräger Alcotest
®
5820
1)
is used for measuring the alcohol
concentration in the breath of a human. The measurement is used as
an indication for alcohol intoxication. Based on the measurement
results no therapeutic measures should be initiated.
1) Alcotest is a registered trademark of Dräger.
