Dräger CPS 7900

Technical data
Dräger CPS 7900 33
9.4 Resistance to the permeation of
chemicals according to EN 943-2:2002
For European approval, the tests against the concentrated
chemicals listed below took place by means of complete
wetting/coverage of the test samples.
The classification for testing the resistance to the permeation
of chemicals is given in accordance with EN 943-1:2015 as
follows:
Based on the tests in accordance with section 5.2 of the
EN 943-2:2002, the following suit configurations are not
suitable for the continuous loading with chemicals where only
one permeation class <2 is reached.
The components of the chemical protective suit have been
tested for the chemicals listed below under laboratory
conditions. The chemical protective suit period of use can
depend on several factors, including the concentration and
state of matter of the contaminant and the ambient conditions.
Additional information is available from Dräger or at http://
www.draeger.com/voice. You need to log on to be able to use
the database.
Class 1: >10 minutes
Class 2: >30 minutes
Class 3: >60 minutes
Class 4: >120 minutes
Class 5: >240 minutes
Class 6: >480 minutes
D-mex Fastener system without
cover
Seams
Test chemicals
in min. Class in min. Class in min. Class
Acetone >540 6 >30 2 >540 6
Acetonitrile >540 6 >30 2 >540 6
Ammonia >540 6 >480 6 >540 6
Chlorine >540 6 >480 6 >540 6
Hydrogen chloride >540 6 >480 6 >540 6
Dichloromethane >540 6 >60 3 >120 4
Diethylamine >540 6 >120 4 >540 6
Ethyl acetate >540 6 >60 3 >540 6
Carbon disulphide >540 6 >480 6 >120 4
Methanol >540 6 >480 6 >540 6
n-Heptane >540 6 >480 6 >540 6
Caustic soda 40 % >540 6 >480 6 >540 6
Sulphuric acid 96 % >480 6 >480 6 >240 5
Tetrahydrofuran >540 6 >30 2 >540 6
Toluene >540 6 >120 4 >540 6
