Dräger FPS-COM 7000 User Manual (English)

Questions and Answers:

C
Charles GarrisonSep 18, 2025
What to do if there is no connection via cable to radio possible in Dräger Respiratory Product?
- K
  Kimberly GreenSep 18, 2025
  If there is no connection via cable to the radio with your Dräger Respiratory Product, the cable might be faulty, so replace it. Check the connection between the cable and the radio, refitting the cable if necessary. Check the connection between the cable and the communication unit and refit the cable if necessary. Ensure you are using a suitable cable.
R
Roberto BushAug 25, 2025
What to do if Dräger Respiratory Product voice amplifier unit is too unclear?
- I
  ibarberAug 25, 2025
  If the voice amplifier unit of your Dräger Respiratory Product sounds unclear, it might be due to a soiled loudspeaker/membrane, so clean the communication unit. Alternatively, there might be water in the loudspeaker; allow the communication unit to dry.
C
coxkarenAug 25, 2025
Why Dräger Respiratory Product has no voice amplifier unit?
- J
  Jessica ColemanAug 26, 2025
  The Dräger Respiratory Product may have no voice amplifier unit because Temporary HazMat mode is selected. Restart the communication unit without HazMat mode. Alternatively, the communication unit might be configured for HazMat mode. Change the configuration with PC software.
J
Joel FlowersAug 27, 2025
What to do if Dräger Respiratory Product communication unit does not react anymore?
- C
  Carly AllisonAug 27, 2025
  If the communication unit stops responding, try pressing the ON/OFF button for at least 15 seconds to power it off. Alternatively, remove and then reinsert the batteries.
A
Amanda BradyAug 27, 2025
What to do if battery compartment of Dräger Respiratory Product cannot be closed or opened?
- P
  Paul GrayAug 27, 2025
  If the battery compartment is difficult to open or close, make sure the screw is completely loosened, lifting it if necessary. Also, check for any blockage of the cover and inspect the sealing, greasing or replacing it as needed. Ensure the path is clear, and carefully open or close the cover. The screw may also block the insert, so lift the screw.
L
Larry GregorySep 13, 2025
Why can members of other groups also be heard on Dräger Respiratory Product?
- S
  Sandra LewisSep 13, 2025
  If you can hear members of other groups in addition to your own on the Dräger Respiratory Product, it might be because the group is used more than once. Check the resource planning and use of groups. You can also try selecting another group.
S
scott47Sep 12, 2025
What to do if Dräger Respiratory Product radio cannot be coupled to communication unit?
- C
  Cory CastilloSep 12, 2025
  If the Dräger Respiratory Product radio cannot be coupled to the communication unit, make sure you are using a suitable insert. Also, check the Bluetooth settings on the radio and couple the communication unit to the radio again.
A
Adam WhiteSep 12, 2025
Why Dräger Respiratory Product has no connection to members of own group?
- E
  Elizabeth TurnerSep 12, 2025
  If there is no connection to members of your own group on the Dräger Respiratory Product, the incorrect group may be set. Select another group.
A
Antonio KingSep 4, 2025
What to do if the pressure switch jams on Dräger FPS-COM 7000 Respiratory Product?
- A
  Angela PayneSep 4, 2025
  If the pressure switch on your Dräger Respiratory Product is jamming, it is likely that the pressure switch is soiled. Clean the pressure switch.
G
Gary WelchSep 2, 2025
How to fix communication unit that will not switch on for Dräger FPS-COM 7000?
- M
  mmckinneySep 2, 2025
  If you cannot switch on the communication unit of your Dräger Respiratory Product, it could be due to several reasons. The batteries might be depleted, so replace them. The batteries might not be inserted correctly; insert them according to the markings. The ON/OFF button might be soiled; clean the ON/OFF button. You might have temporarily selected HazMat mode; restart the communication unit without HazMat mode.

Dräger FPS-COM 7000 Specifications

General

Operating Time	Up to 10 hours
Water Resistance	IP67
Frequency Range	400 - 470 MHz
Bluetooth	Yes
Hands-free Function	Yes
Approval	EN 137
Ambient Temperature	-30 °C to +60 °C
Loudspeaker Volume	Up to 95 dB
Product Type	Communication Device
Communication System	Digital radio communication
Compliance Standards	EN 137
Operating Temperature Range	-30 °C to +60 °C

Summary

Safety Information

General Safety Instructions

Provides essential information for the proper use of the communication unit.

Warning Symbol Explanations

Defines warning signs used in the document for user attention and safety.

Product Description

Overview and Components

Provides a visual guide to the communication unit's components and their numbering.

Technical Features and Functions

Details the technical specifications, functions, and operational capabilities of the communication unit.

Product Functionality and Usage

Communication Principles

Explains the functional principles of team radio and tactical radio communication.

Intended Use, Limitations, and Approvals

Covers the product's intended use, limitations, and provides information on product approvals.

Available Inserts

Lists the different types of inserts available for the communication unit.

Using the Communication Unit

General Operating Instructions

Covers unit behavior, status display, accessory connection, and power operations.

Switching On and Off

Details the procedure for turning the communication unit on and off.

Unit Operation and Configuration

HazMat Mode and Volume Adjustment

Details switching to HazMat mode and adjusting the volume controller.

Group Selection and Configuration

Explains how to select groups and configure the communication unit via PC software.

Preparations and Insert Fitting

Covers preparations for first use and fitting the correct insert.

Pre-Use Preparations

Fitting the Unit and Radio Pairing

Guides on attaching the unit to the facepiece and pairing it with a radio via Bluetooth.

Checking Readiness for Use

Outlines the steps to ensure the unit and radio are ready for operation before starting a shift.

During Use and Troubleshooting

During Use Guidelines

Provides cautions and notices for using the unit during operation, including Bluetooth connection interruptions.

Troubleshooting General Issues

Lists common faults like unit not switching on or no voice amplification, with their causes and remedies.

Troubleshooting Details

Voice and Earphone Issues

Addresses problems with voice amplification clarity, earphone volume, and output.

Bluetooth and Mechanics Troubleshooting

Covers Bluetooth pairing issues and mechanical problems with the battery compartment.

Maintenance and Troubleshooting

Unit Fitting and Cable Issues

Details troubleshooting for fitting/removing the unit, cable connections, and push-button/switch issues.

Maintenance Intervals

Specifies the recommended maintenance intervals for checking the unit's functionality.

Cleaning and Maintenance

Cleaning Procedures

Provides detailed steps for cleaning the communication unit and its components, including drying.

Maintenance Work Overview

Introduces maintenance tasks and highlights precautions for assembly work.

Component Maintenance

Battery and Earphone Replacement

Details procedures for replacing batteries and earphones, including safety warnings.

Fastening Eye and Unit Dismantling

Guides on replacing fastening eyes and dismantling the communication unit from the facepiece.

Transport, Storage, and Disposal

Firmware Updates and Transport

Covers installing firmware updates and methods for transporting the communication unit.

Storage, Disposal, and Technical Data

Provides guidelines for storing, disposing of the unit, and lists technical data.

Order List

Product and Accessory Ordering

Lists designations and corresponding order numbers for the communication unit and its accessories.

Warranty Information

Warranty Terms and Conditions

Outlines the warranty terms, conditions for claims, and the importance of following instructions for use.
