Dräger Oxylog User Manual

---- --y -‘(
Name and description
Order No.
Special accessories for pressure reducer D 20225:
O2 coupling hose, 0.15 m
Connection hoses between Oxylog and cylinder pack
option of:
a) screw-type both ends, option of
O2 compressed-air connecting hose, 1.5 m
or
M 23 874
M 17616
O2 compressed-air connecting hose, 3 m
b) When using O2 coupling hose M 23874,
plug-type via quick-release coupling,
thread M 15 x 1 at device end, option of:
O2 compressed-air connecting hose, 3 m
(angled plug connector)
or
M 17617
M 22 494
O2 compressed-air connecting hose, 5 m
(angled plug connector)
M 22 495
Special accessories
Silicone mask, No. 2
Silicone mask, No. 5
Holder
to secure Oxylog in mobile units
Holder with rail bracket
to attach Oxylog to wall rail
Connecting hose, 3 m
(Oxett/Oxylog)
Pressure limiting valve
adjustable from IO to 45 mbar, to be latched onto patient
connection
Volume measurement Oxylog
auxiliary means for measurement of expired volume com-
prising: Volumeter, support, silicone hose 1.1 m and 2 sockets
PEEP valve (Ambu PEEP)
adjustable from 0 to 10 mbar
Polymed 201 (gas blender)
and
21 20 194
21 20 186
84 04 560
84 05 009
M 25 879
84 05 390
84 06 995
84 07 475
D 21 800
02 compressed-air connecting hose, 1.5 m
M 17716
Continued next page

Dräger Oxylog Specifications

General

Power Source	AC Power, Internal Battery
Peak Flow	Up to 120 L/min
Type	Ventilator
Operating Modes	SIMV
Tidal Volume Range	50 mL to 2000 mL
PEEP	0 to 20 cm H2O
FiO2	21 to 100 %
