Order List
Name and description
Order No.
Basic unit
Oxylog
84 09 520
time-cycled, volume constant ventilator for controlled ventilation
in emergency medicine. Including accessories, comprising:
ventilation tubing and non-rebreathing valve.
Oxylog with spontaneous breathing
84 09 585
Standard equipment
For operation from oxygen cylinder:
O2 pressure reducer, G 314
and
D 17251
O2 cylinder AG 2.51200, G 314
straight valve, filled
or
B 03 580
O2 cylinder AG 1 l/200, G 314
straight valve, filled
and
B 02710
OS compressed-air connecting hose, 1.5 m
or
M 17816
O2 compressed-air connecting hose, 3 m
For operation from central supply unit
option of:
M 17617
O2 compressed-air connecting hose, 3 m
(angled plug connector)
or
M 22 494
O2 compressed-air connecting hose, 5 m
(angled plug connector)
M 22 495
For operation from portable O2 cylinder pack
Cylinder support
for two 2 L cylinders
M 23 370
Use of 2 x 2 L cylinders is possible
OS pressure reducer (G 3/4)
and
D 20 225
O2 cylinder AG 21200, G 314
straight valve, filled
and
Spanner SW 32/22 (hexagonal)
B 02 352
M 12401
24

Dräger Oxylog Specifications

General

Power Source	AC Power, Internal Battery
Peak Flow	Up to 120 L/min
Type	Ventilator
Operating Modes	SIMV
Tidal Volume Range	50 mL to 2000 mL
PEEP	0 to 20 cm H2O
FiO2	21 to 100 %
