Dräger Oxylog User Manual

e
No. in
Fig. 11
Designation and description
Order No.
‘age 28
l-7
Oxyfog with ventilation accessories
84 09 520
1
Oxylog
84 08 500
2
Silicone tubing E 1.1 m
84 04 063
3-5
Non-rebreathing valve
84 06 600
3
Cover
84 06 585
4
Diaphragm
84 03 552
5
Valve housing
84 06 595
67
Carrying strap
84 04 773
6
Strap
84 04 078
7
Buckle
8405 179
8
Pressure limiting valve
84 05 390
9
PEEP valve (Ambu) O-10 mbar
84 07 475
10
Silicone mask, No. 2
21 20 194
10
Silicone mask, No. 5
21 20 186
12
Holder
84 04 560
13
Holder with bracket
84 05 009
2, 14-17
Voiumeter connection
84 06 995
14
Socket
M 25 647
15
Socket, complete
84 05 155
16
Volumeter 3000
2M 18250
17
Retainer
84 06 677
Parts List
c/t 27

Dräger Oxylog Specifications

General

Power Source	AC Power, Internal Battery
Peak Flow	Up to 120 L/min
Type	Ventilator
Operating Modes	SIMV
Tidal Volume Range	50 mL to 2000 mL
PEEP	0 to 20 cm H2O
FiO2	21 to 100 %
