REGARD 7000 configuration software
1. Select [Docking Station] > [Module] > [Port].
2. Select > Measurement range assistant.
 The wizard for setting the target gas is displayed.
3. Enter the parameters.
4. Confirm the selection with .
10.9 Create component and parameter reports
10.9.1 Create and save component report
1. In the menu bar, select Reports > Component Report....
 A dialog window is displayed.
2. In the dialog window, select a save location and name the file. Then select .
ᅚ The report is saved as a PDF file.
10.9.2 Create and save parameter report
1. In the menu bar, select Reports > Parameter Report....
 A dialog window is displayed.
2. In the dialog window, select a save location and name the file. Then select .
ᅚ The report is saved as a PDF file.
10.10 Display Dashboard view
The Dashboard view represents the Dashboard screen of the REGARD 7000
system and therefore provides the complete range of functions for operating the
system. The function is closed following 15 minutes of inactivity.
Requirements:
– REGARD 7000 is connected to the PC.
– Configuration port is configured.
1. In the toolbar, select or in the menu bar, select Maintenance > Dashboard
View....
2. A window is displayed with the dashboard view.
10.11 Select the PC interface
1. In the menu bar, select Settings > Network Adapter....
 A dialog window is displayed.
2. In the dialog window Select Network Adapter select the required PC interface
and confirm with .
Dräger recommends deactivating all network services and TCP/IP stacks for the
Ethernet connection to the REGARD 7000 system. To retain this setting, a
dedicated Ethernet connection with a USB Ethernet adapter should be used.
