Dräger VarioGard 2300 User Manual

12 Dräger VarioGard 2300 / 2320
Installation
3 Installation
Details on the mechanical installation and the wiring diagram are
available in the VarioGard 23x0 installation instructions (order no.
90 33 469).
4 Operation
VarioGard 23x0 transmitter
 For monitoring of the ambient
air, depending on the sensor
installed.
 Three-coloured optical LED.
 Contact points for operation
using a magnetic wand.
5 Configuration
Use the PC software VarioCal to prepare calibration and to adjust gas
settings.
6 Maintenance
Visual inspection
At least every 3 months to determine operational readiness.
Routine inspections
Dräger recommends having the system inspected by Dräger Service
at least once a year.
When necessary
 Replace the sensors of the transmitters.
Calibration of transmitters
The calibration can be carried out with the magnetic wand (order no.
45 43 428) directly on the transmitter.
Handling the magnetic wand:
Each transmitter has two contact
points labelled with and
on the housing. Place the
magnetic wand on the contact
points for calibration.
00233185.eps
VarioGard
CAUTION
Always calibrate the zero-point before span.
!
00833185.eps
VarioGard
