Dragino LSN50 User Manual

www.dragino.com
LSN50 LoRa Sensor Node User Manual 54 / 60
For example, in US915 band, the frequency table is as below. By default, the end node will
use all channels (0~71) for OTAA Join process. After the OTAA Join, the end node will use
these all channels (0~71) to send uplink packets.
CHE
US915 Uplink Channels(125KHz,4/5,Unit:MHz,CHS=0)
0
ENABLE Channel 0-63
1
902.3
902.5
902.7
902.9
903.1
903.3
903.5
903.7
Channel 0-7
2
903.9
904.1
904.3
904.5
904.7
904.9
905.1
905.3
Channel 8-15
3
905.5
905.7
905.9
906.1
906.3
906.5
906.7
906.9
Channel 16-23
4
907.1
907.3
907.5
907.7
907.9
908.1
908.3
908.5
Channel 24-31
5
908.7
908.9
909.1
909.3
909.5
909.7
909.9
910.1
Channel 32-39
6
910.3
910.5
910.7
910.9
911.1
911.3
911.5
911.7
Channel 40-47
7
911.9
912.1
912.3
912.5
912.7
912.9
913.1
913.3
Channel 48-55
8
913.5
913.7
913.9
914.1
914.3
914.5
914.7
914.9
Channel 56-63
Channels(500KHz,4/5,Unit:MHz,CHS=0)
903
904.6
906.2
907.8
909.4
911
912.6
914.2
Channel 64-71
When you use the TTN network, the US915 frequency bands use are:
● 903.9 - SF7BW125 to SF10BW125
● 904.1 - SF7BW125 to SF10BW125
● 904.3 - SF7BW125 to SF10BW125
● 904.5 - SF7BW125 to SF10BW125
● 904.7 - SF7BW125 to SF10BW125
● 904.9 - SF7BW125 to SF10BW125
● 905.1 - SF7BW125 to SF10BW125
● 905.3 - SF7BW125 to SF10BW125
● 904.6 - SF8BW500
Because the end node is now hopping in 72 frequency, it makes it difficult for the devices to
Join the TTN network and uplink data. To solve this issue, you can access the device via the
AT commands and run:
AT+CHE=2
ATZ
to set the end node to work in 8 channel mode. The device will work in Channel 8-15 & 64-
71 for OTAA, and channel 8-15 for Uplink.
The AU915 band is similar. Below are the AU915 Uplink Channels.
CHE
AU915 Uplink Channels(125KHz,4/5,Unit:MHz,CHS=0)
0
ENABLE Channel 0-63
1
915.2
915.4
915.6
915.8
916
916.2
916.4
916.6
Channel 0-7
2
916.8
917
917.2
917.4
917.6
917.8
918
918.2
Channel 8-15
3
918.4
918.6
918.8
919
919.2
919.4
919.6
919.8
Channel 16-23
4
920
920.2
920.4
920.6
920.8
921
921.2
921.4
Channel 24-31
5
921.6
921.8
922
922.2
922.4
922.6
922.8
923
Channel 32-39
6
923.2
923.4
923.6
923.8
924
924.2
924.4
924.6
Channel 40-47
7
924.8
925
925.2
925.4
925.6
925.8
926
926.2
Channel 48-55
8
926.4
926.6
926.8
927
927.2
927.4
927.6
927.8
Channel 56-63
Channels(500KHz,4/5,Unit:MHz,CHS=0)
915.9
917.5
919.1
920.7
922.3
923.9
925.5
927.1
Channel 64-71
