Draper MS250 - OPERATION & USE (continued); Performing Bevel and Compound Cuts

BEVEL CUT
When a bevel cut is required, tilt the blade to the
desired bevel angle. Stand to the left side of the
handle to make the cut (Fig.24).
COMPOUND CUT
When a compound cut is required, select the correct
bevel and mitre position. Move with the handle to the
mitre angle to make the cut. (Fig.25).
OPERATION & USE
- 14 -
Fig.24.
Fig.25.
