Vigor130 Series User’s Guide
25
Physical Mode
Display the physical mode of such WAN interface.
DSL Mode
Specify which DSL mode can be used for such WAN
connection.
Auto – The system will choose the suitable one
automatically.
VLAN Tag insertion
Enable – Enable the function of VLAN with tag.
The modem will add specific VLAN number to all packets
on the WAN while sending them out.
Please type the tag value and specify the priority for the
packets sending by WAN1.
Disable – Disable the function of VLAN with tag.
Tag value – Type the value as the VLAN ID number. The
range is form 0 to 4095.
Priority – Type the packet priority number for such VLAN.
The range is from 0 to 7.
After finished the above settings, click OK to save the settings.
