Draytek Vigor130 - LED Indicators and Connectors

Vigor130 Series User’s Guide
2
1
1
.
.
2
2
L
L
E
E
D
D
I
I
n
n
d
d
i
i
c
c
a
a
t
t
o
o
r
r
s
s
a
a
n
n
d
d
C
C
o
o
n
n
n
n
e
e
c
c
t
t
o
o
r
r
s
s
Before you use the Vigor modem, please get acquainted with the LED indicators and
connectors first.
LED Status Explanation
Off The system is not ready or is failed. ACT
Blinking The system is ready and can work normally.
On A normal connection is through its corresponding
port.
Off LAN is disconnected.
LAN
Blinking Data is transmitting (sending/receiving).
On The DoS/DDoS function is active. DoS
Blinking It will blink while detecting an attack.
On DSL connection synchronized. DSL
Blinking DSL connection is synchronizing.
