Vigor130 Series User’s Guide
27
provided by ISP.
Protocol - Drop down the list to choose the protocol, PPPoE or
PPPoA.
Modulation – Choose a suitable method for PPPoE/PPoA
connection.
PPPoE Pass-through
The modem offers PPPoE dial-up connection. Besides, you
also can establish the PPPoE connection directly from local
clients to your ISP via the Vigor modem. When PPPoA
protocol is selected, the PPPoE package transmitted by PC will
be transformed into PPPoA package and sent to WAN server.
Thus, the PC can access Internet through such direction.
For Wired LAN – If you check this box, PCs on the same
network can use another set of PPPoE session (different with
the Host PC) to access into Internet. However, if this box is
checked in PPPoA protocol, only PPPoE clients on the LAN
will be served and only one session is allowed.
VLAN Enable - Enable the function of VLAN with tag. The
modem will add specific VLAN number to all packets while
sending them out. Please type the tag value and specify the
priority for the packets sent by the modem.
VLAN ID –Type the value as the VLAN ID number. The
range is form 1 to 4095.
Priority (802.1p) - Type the packet priority number for such
VLAN. The range is from 0 to 7.
WAN Connection
Detection
Such function allows you to verify whether network
connection is alive or not through ARP Detect or Ping Detect.
Mode – Choose ARP Detect or Ping Detect for the system to
execute for WAN detection.
Ping IP – If you choose Ping Detect as detection mode, you
have to type IP address in this field for pinging.
TTL (Time to Live) – Displays value for your reference. TTL
value is set by telnet command.
MTU
It means Max Transmit Unit for packet. The default setting
will be 1442.
ISP Access Setup
Enter your allocated username, password and authentication
parameters according to the information provided by your ISP.
If you want to connect to Internet all the time, you can check
Always On.
ISP Name – Type the name of the ISP if required.
Username – Type in the username provided by ISP in this
field.
Password – Type in the password provided by ISP in this
field.
PPP Authentication – Select PAP only or PAP or CHAP for
PPP.
Always On - If you want to connect to Internet all the time,
check the Always On box.
Idle Timeout – Set the timeout for breaking down the Internet
after passing through the time without any action. This setting
