Vigor130 Series User’s Guide
84
Index
Display the profile number that you can configure.
Name
Display the name of the group profile.
To set a new profile, please do the steps listed below:
1. Click the number (e.g., #1) under Index column for configuration in details.
2. The configuration page will be shown as follows:
Available settings are explained as follows:
Item Description
Name
Type a name for this profile. Maximum 15 characters are
allowed.
Interface
Choose WAN, LAN or Any to display all the available IP
objects with the specified interface.
Available IP Objects
All the available IP objects with the specified interface
chosen above will be shown in this box.
Selected IP Objects
Click >> button to add the selected IP objects in this box.
3. After finishing all the settings here, please click OK to save the configuration.
