3
[Firewall] > [General Setup])
Off
Web Content Filter is inactive
2.4G / 5G
(Wireless LAN)
On
2.4G: 2.4GHz Access Point is active
5G: 5GHz Access Point is active
Off
Wireless Access point is inactive
Blinking
2.4GHz/5GHz LED will blink slowly when
transmitting over that interface
ACT & WLAN LEDs blink rapidly when WPS is
ready for WPS clients to connect. After 2
minutes, the router will disable WPS pairing
mode
DMZ
On
DMZ Port is enabled
Off
DMZ Port is not enabled
Blinking
Data is being transmitted through DMZ Port
LED on Connector
(2)
WAN2 / P6
Left LED
On
Ethernet WAN (RJ45) is connected
Off
Ethernet WAN is disconnected
Blinking
Data is transmitting (sending/receiving)
Right LED
On
The port is connected with 1000Mbps
Off
The port is connected with 10/100Mbps
LAN P1~P5
Left LED
On
Ethernet LAN (RJ45) is connected
Off
Ethernet LAN is disconnected
Blinking
Data is transmitting (sending/receiving)
Right LED
On
The port is connected with 1000Mbps
Off
The port is connected with 10/100Mbps
The port “WAN2 / P6” is switchable. It can be used for LAN connection or WAN
connection according to the settings configured in WUI.
