Draytek VigorAP 802 Quick Start Guide

Descriptions of Components
LED Status Explanation
ACT
Off The VigorAP is powered off.
Blinking Slowly: The VigorAP is ready and operating
normally.
Quickly: The system is booting up or resetting to
the Factory Default value.
2.4G
On 2.4GHz Access Point is active.
Off 2.4GHz Access Point is turned off.
Blinking Data is being transmitted on the AP’s 2.4GHz
wireless interface.
5G
On 5GHz Access Point is active.
Off 5GHz Access Point is turned off.
Blinking Data is being transmitted on the AP’s 5GHz
wireless interface.
LAN
On Ethernet LAN (RJ45) is connected.
Off Ethernet LAN is disconnected.
Blinking Data is transmitting (sending/receiving).
Uplink
On
AP mode: The Ethernet cable is connected.
Mesh Node: Connected to Mesh network.
Range Extender: Connected to Wireless Network.
Off
AP mode: The Ethernet cable is not connected.

Draytek VigorAP 802 Specifications

General

Brand	Draytek
Model	VigorAP 802
Category	Wireless Access Point
Language	English
