Draytek VigorAP 906 Quick Start Guide

6
4
4
.
.
C
C
o
o
n
n
n
n
e
e
c
c
t
t
i
i
o
o
n
n
a
a
n
n
d
d
C
C
o
o
n
n
f
f
i
i
g
g
u
u
r
r
a
a
t
t
i
i
o
o
n
n
This section will guide you to configure AP settings to establish wireless network
through a web browser.
1. Make sure your PC connects to the device correctly.
2. Open a web browser on your PC and type http://192.168.1.2. A pop-up
window will open to ask for username and password. Pease type
“admin/admin” on Username/Password and click Login.
Note You may either simply set up your computer to get IP dynamically
from the router or set up the IP address of the computer to be in
the same subnet as the IP address of VigorAP 906.
 If there is no DHCP server on the network, then VigorAP 906
will have an IP address of 192.168.1.2.
 If there is DHCP available on the network, then VigorAP 906
will receive its IP address via the DHCP server.
 If you connect to VigorAP by wireless LAN, you could try to
access the web user interface through http://vigorap.com.

Draytek VigorAP 906 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Placement	Ceiling, Table, Wall
Product color	White
Security algorithms	WEP, WPA, WPA2, WPA3, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	5
Antenna type	External
Antenna direction type	Omni-directional
Antenna gain level (max)	2.5 dBi
Input current	0.4 A
Output current	1.5 A
AC input voltage	48 - 56 V
DC voltage range	12 V
Power consumption (max)	17.3 W
Sustainability certificates	CE
