Draytek VigorAP 906 Quick Start Guide

iv
Declaration of Conformity
Hereby, DrayTek Corporation declares that the radio equipment type VigorAP 906 is in compliance with Directive
2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address:
https://fw.draytek.com.tw/VigorAP 906/Document/CE/
Manufacturer: DrayTek Corp.
Address: No. 26, Fushing Rd, Hukou, Hsinchu Industrial Park, Hsinchu 303, Taiwan
Product: VigorAP 906
Frequency Information for Europe area:
2.4GHz WLAN 2400MHz - 2483MHz, max. TX power: 19.81dBm *1
5GHz WLAN 5150MHz - 5350MHz, max. TX power: 22.70dBm *2
5470MHz - 5725MHz, max. TX power: 29.47dBm *2
Requirements in AT/BE/BG/CZ/DZ/DK/EE/FR/DE/IS/IE/IT/EL/ES/ CY/LV/LI/LT/
LU/HU/MT/NL/NO/PL/PT/RO/SI/SK/TR/FI/SE/CH/HR. 5150MHz~5350MHz is for
indoor use only.
(*1: for 2.4GHz WLAN model; *2: for 5GHz WLAN model)
This product is designed for 2.4GHz and 5GHz WLAN network throughout the EC region.
Declaration of Conformity
Hereby, DrayTek Corporation declares that the radio equipment type VigorAP 906 is in compliance with
Regulation SI 2017 No. 1206.
Manufacturer: DrayTek Corp.
Address: No. 26, Fushing Rd, Hukou, Hsinchu Industrial Park, Hsinchu 303, Taiwan
Product: VigorAP 906
Importer: CMS Distribution Ltd: Bohola Road, Kiltimagh, Co Mayo, Ireland
Frequency Information for UK area:
2.4GHz WLAN 2400MHz - 2483MHz, max. TX power: 19.81dBm *1
5GHz WLAN 5150MHz - 5350MHz, max. TX power: 22.70dBm *2
5470MHz - 5725MHz, max. TX power: 29.47dBm *2
Requirements in UK. 5150MHz - 5350MHz is for indoor use only.
(*1: for 2.4GHz WLAN model; *2: for 5GHz WLAN model)
This product is designed for 2.4GHz and 5GHz WLAN network use in the UK & Ireland.
Caution
 Any changes or modifications not expressly approved by the grantee of this device could void the user's
authority to operate the equipment.
 Any changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate this equipment.
 This equipment complies with CE RF radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm between the radiator &
your body.
 Operations in the 5.15-5.35GHz band are restricted to indoor usage only.

Draytek VigorAP 906 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Placement	Ceiling, Table, Wall
Product color	White
Security algorithms	WEP, WPA, WPA2, WPA3, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	5
Antenna type	External
Antenna direction type	Omni-directional
Antenna gain level (max)	2.5 dBi
Input current	0.4 A
Output current	1.5 A
AC input voltage	48 - 56 V
DC voltage range	12 V
Power consumption (max)	17.3 W
Sustainability certificates	CE
