Parts Needed
ASCEND Shower Door Manual Ver 1 022021 15
© 2021 DreamLine® All Rights Reserved
Tools Needed
Fig 8
11
x1
12
x1
NOTE
Once the door is adjusted to level and plumb, use the long end of an Allen Wrench to install the M6 x
10mm Screw (#11) and the Lock Washer (#12) to secure the two Brackets inside the Profiles. Fig 8
8
