Tools Needed
Parts Needed
ASCEND Shower Door Manual Ver 1 022021 22
© 2021 DreamLine® All Rights Reserved
Fig 15
From inside the shower, close the Door Glass and mark the Sweep Vinyl (#19) at the edge of the Strike
Vinyl (#18). Use a razor knife to remove just the inside aspect of the Strike Vinyl, so the Door Glass closes
cleanly against the Strike Vinyl. Fig 15
NOTE
17
x1
Inside Shower
2
1
19
x1
15
To Next Page
