Tools Needed
Parts Needed
ASCEND Shower Door Manual Ver 1 022021 21
© 2021 DreamLine® All Rights Reserved
Fig 14
Make any final adjustments to the shower door. Open the Door Glass and Drill Ø 1/8” holes through the
pre-drilled holes in both Glass Profiles. Drill through one layer of the Wall Profiles. Use a Phillips
Screwdriver to install the Washers and Caps (#14) and ST4.0x 10mm Pan Head Screws (#14). Fig 14
NOTE
13
x7
CapScrewWasher
2
1
14
x7
14
