24
Observe all provided
warnings and safety
instructions when using the Dremel 3D40.
Failure to do so may result in fire, equipment
damage, property damage or personal injury.
Do not touch the extruder
tip during operation or
until it has cooled down to at least 60°C
(140°F). Contact with the extruder tip during
or after operation before tip has cooled may
result in personal injury.
Use only DREMEL filament.
Use of filament not
authorized by Dremel may result in
equipment and property damage.
Do not pull the filament
out. Doing so may damage
the extruder.
LOADING/CHANGING FILAMENT
1. Start filament load/change process by
tapping “Filament” button on touchscreen.
Extruder will move to front right corner of
print area and extruder tip will begin to
heat.
2. After extruder stops moving, open the
3D40 Lid for better access to extruder.
3. If existing filament is loaded, cut existing
filament near extruder intake and tap
“Next” button on touchscreen.
4. Remove Spool door by rotating it counter
clockwise and remove existing spool if
one is present, see figure 1.
Getting Ready to Build
!
WARNING
Open
Close
!
WARNING
Filament
Filament
Guide Tube
Spool
Holder
FIG. 1
!
CAUTION
!
WARNING
