Dremel 6800 - Operating Instructions - Continued; Depth Adjustment and Base Plate; Trigger Operation and Lock-On Feature; Variable Speed Dial and Over Current Protection

11
&<@2920AA52?645A@=2213<?2.057</B@2.
=?.0A602=6202<3:.A2?6.9
!"& %=221 6@ .3320A21 /F C<9A.42
05.;42@  ?21B0216;0<:6;4 C<9A.42D699
@9<DA52$# <3A52A<<9
+<B? A<<9 6@ 2>B6==21 D6A5 . 3<91 /.08
@F@A2: A< =?<A20A A52 :<A<? 3 A52 A<<9
@A.?A@A</<41<D;1B?6;4B@22.@2<33<;
3221=?2@@B?2
+<B?A<<96@.9@<2>B6==21D6A5@<3A@A.?A@<
6A 6@ ;<?:.9 3<? A52 A<<9 A< 4?.1B.99F
.002992?.A2B;A696A?2.052@6A@36;.9@=221
"($'$$!&#$"&&"!
Your tool is equipped with over current
protection that will slow the motor automatically
when overstressed. When this occurs you
should reduce cutting pressure, rate of cut and
the tool will increase speed again for maximum
cutting performace.
($%#
Your tool is equipped with a variable speed
dial. The speed may be adjusted during
operation by presetting the dial on or between
any one of the settings (Fig. 8).
&$$I"!"J%)&
To turn tool “ON”, squeeze the trigger switch. To
turn the tool “OFF”, release the trigger switch
which is spring loaded and will return to “OFF”
position automatically (Fig. 7).
""!'&&"!
The "Lock-ON" button, located in the handle of
your tool allows for continuous operation
without holding the trigger (Fig. 7).
TO LOCK TRIGGER "ON": squeeze trigger,
depress "Lock-ON" button and release trigger.
TO UNLOCK THE TRIGGER: squeeze trigger
and release it without depressing the "Lock-
ON" button.
If the “Lock-ON” button is
continuously being depressed,
the trigger can not be released.
#&'%& !&
Loosen the depth adjustment thumb screw
(counter-clockwise) to change the depth of
cut. Slide the base plate to the desired depth
of cut (about 1/8" greater than material
thickness when cutting completely through
something) and re-tighten the thumb screw
(clockwise) (Fig. 6).
The maximum base plate travel is 1-1/4”.
!<A2 If you over loosen the thumb screw, the
nut, thumb screw and base plate can
completely come free from the tool. To
reassemble, first insert nut then base and finally
the thumb screw.
!<A2 If after loosening the thumb screw the
base plate does not freely move up and down
twist it back and forth slightly and then move it
to desired position.
"LOCK-ON"
BUTTON
TRIGGER “ON-OFF”
SWITCH
DEPTH
ADJUSTMENT
THUMB SCREW
1/8"
FIG. 6
FIG. 7
4
VARIABLE
SPEED DIAL
SLOWER
FASTER
FIG. 8
!
WARNING
