Mess- und
Regeltechnik
Beschreibung und
Bedienungsanleitung
Description and
Operating Manual
Heizstrom- und
Heizkreisüber-
wachungsmodul
Heating current and circuit
monitoring module
Module de surveillance du
courant et du circuit de
chauffage
HCC 11

Table of Contents

Questions and Answers

  • K
    kelseysmithAug 3, 2025
    Why does the red LED come on my Drews HCC 11 Control Unit?
    • J
      Jasmine BrownAug 3, 2025
      The red LED might illuminate due to several reasons: * There could be an interruption in the circuit or load, so you should check those. * There might be a partial load condition; inspect the load. * A fuse might have blown; check and replace it if necessary. * The SSR might be malfunctioning; check the SSR. * The current could be outside the monitoring window, so adjust the current accordingly.
  • A
    Angela PollardAug 13, 2025
    What to do if the green LED does not come on in Drews HCC 11?
    • J
      Jason AllenAug 13, 2025
      If the green LED isn't lighting up, it could be due to: * A missing auxiliary supply or reversed polarity. Check the auxiliary supply and its polarity. * The absence of a control signal. Make sure the control signal is present.
  • M
    Matthew WalkerAug 22, 2025
    What to do if the red LED comes on and there is no HIGH-signal at output in Drews HCC 11 Control Unit?
    • C
      crystalkeithAug 23, 2025
      If the red LED is on and there's no HIGH-signal at the output, the cause may be: * A short circuit or overload at the output; inspect for these conditions. * Sw6 being set to ON, which inverts the alarm output; check the setting of Sw6.

Summary

HCC-11 Module Application

HCC-11 Safety Regulations

HCC-11 Wiring Diagram

HCC-11 Assembly Instructions

HCC-11 Starting Up

HCC-11 Troubleshooting

HCC-11 Technical Data
