Module Attachment
Warning: Please ensure that the connectors are plugged together; if securement pins have locked
into place, but the connector remained undocked; remove the module and repeat attachment.
During step 2, you may press the module firmly on the connector side area, to ensure connector
docking before securement pins locking into place.
SCREEN + CAMERA POWER ON/OFF
The LCD module will turn on/o automatically when docked onto the Ghost 4K.
1. Press and hold the button to power the camera and LCD module on.
2. To power o, press and hold the button for 3 seconds.
Before installing,
please ensure that the
camera is powered
o. To attach, follow
these instructions:
1. Place the module
on the camera
body, ensuring that
the module’s 30
pin connector is
above the camera’s
female connector.
2. Press down
on both ends
simultaneously,
until the module
clicks into place.
