41
RTS HUMIDIFIER RX SERIES INSTALLATION, OPERATION, AND MAINTENANCE MANUAL
Outdoor enclosure: Mounting
INSTALLATION
FIGURE 41-1: OUTDOOR ENCLOSURE MOUNTED FLUSH
FIGURE 41-2: OUTDOOR ENCLOSURE MOUNTED ON A CURB
OM-8091
OM-8090
A
B
C
A
B
DIMENSIONS
• For outdoor unit weights, see pages 8 - 9.
• For clearances, see Figure 43-1.
Steam outlet
D
E
14" - 36" in
(356 - 914 mm)
2" (51 mm)
increments
