RTS HUMIDIFIER RX SERIES INSTALLATION, OPERATION, AND MAINTENANCE MANUAL
Models, capacities, and electrical specifications
SPECIFICATIONS
Table 4-1:
RTS humidifier capacities, electrical specifications
RTS
model
Maximum steam
capacity
Power Stages
Total max current draw (amps)
Single-phase Three-phase
lbs/hr kg/h kW Contactors 120V 208V 240V 277V 480V 600V 208V 240V 380V 480V 600V
RX-6-1 6 2.7 2 1 16.7 9.6 8.3 21.7 4.2 3.3 — — — — —
RX-12-1 12 5.4 4 1 33.3 19.2 16.7 21.7 8.3 6.7 16.7 14.4 9.10 7.2 5.8
RX-18-1 18 8.2 6 1 — 28.9 25 21.7 12.5 10 16.7 14.4 9.10 7.2 5.8
RX-24-1 24 10.9 8 1 — 38.5 33.3 43.3 16.7 13.3 25 21.7 13.70 10.8 8.7
RX-30-1 30 13.6 10 1 — — 41.7 43.3 20.8 16.7 33.3 29.9 18.20 14.4 11.6
RX-36-1 36 16.3 12 1 — — — 43.3 25 20 33.3 28.9 18.20 14.4 11.6
RX-42-1 42 19.0 14 1 — — — — 29.2 23.3 41.6 36.1 22.80 18 14.4
RX-48-1 48 21.8 16 1 — — — — 33.3 26.7 — 43.3 27.40 21.7 17.3
RX-63-1 63 28.6 21 1 — — — — 43.8 35 — — 34.2 27.1 21.7
RX-75-1 75 34.0 25 1 — — — — — 45 — — 41 32.5 26
RX-30-2 30 13.6 10 2 — 57.7 — — — — — — — — —
RX-36-2 36 16.3 12 2 — 57.7 50 — — — — — — — —
RX-48-2 48 21.8 16 2 — 76.9 66.7 86.6 — — 50 — — — —
RX-63-2 63 28.6 21 2 — — 91.7 86.6 — — 66.6 57.7 — — —
RX-75-2 75 34.0 25 2 — — — — 54.2 — 83.2 72.2 — — —
RX-90-2 90 40.8 30 2 — — — — 62.5 50 — 86.6 54.7 43.3 34.6
RX-102-2 102 46.3 34 2 — — — — 70.8 56.7 — 86.6 54.7 43.3 34.6
RX-126-2 126 57.1 42 2 — — — — 87.5 70 — — 68.4 54.1 43.3
RX-144-2 144 65.3 48 2 — — — — — 80 — — 82 65 52
RX-162-2 162 73.5 54 2 — — — — — 90 — — 82 65 52
• All RTS humidifier models operate at 50/60 Hz.
• For wire sizing, the highest leg draw is shown due to current imbalance.
• See Table 66-1 for heaters.
• Maximum amps is determined based on the heaters used by each model. Some voltage/kW combinations show higher amperage values than
what the unit capacity will allow.
