DriSteem RX-75-1 - Start-up Commissioning Checklist

48
RTS HUMIDIFIER RX SERIES INSTALLATION, OPERATION, AND MAINTENANCE MANUAL
Supply water
 RO
 DI
 Softened
 Potable
Grains hardness ________________________________
Water pressure ________________ psi
(must be between 25 and 80 psi
[172 and 582 kPa] at 6.0 gpm)
 Supply water piping is 3/4" (DN20) pipe thread or up
sized for longer runs to maintain 25-80 psi at 6.0 gpm.
______________________________________________________
Wiring
 Control transmitter
Gauge _________
 Shield
 High limit duct humidistat
Gauge _________
 Shield
 Airflow proving switch
 External fault contact
 Twisted pair connection between boards
(for multiple units only)
Job site representation:
________________________________________________________
________________________________________________________
________________________________________________________
Job name _______________________________________________
Program code ___________________________________________
DriSteem rep ____________________________________________
 Required clearances (see page 14 and 20)
Steam pipe
Outlet size ________________________________
 Flange
 Hard pipe
 Insulated
 Steam hose (do not insulate)
Rise ________________________________
Run ________________________________
 Pitched back to humidifier
 45° angles used in piping
OPERATION
Start-up commissioning checklist
Important: Troubleshooting information for this humidifier is
located in the Vapor-logic Installation and Operation Manual shipped
with your humidifier. If you do not have this manual, go to
www.dristeem.com to download or order a copy.
Visit date _______________________________________________
Model # ________________________________________________
Serial # _________________________________________________
Tag # ___________________________________________________
Continued
