RTS HUMIDIFIER RX SERIES INSTALLATION, OPERATION, AND MAINTENANCE MANUAL
Outdoor enclosure: Mounting
INSTALLATION
DIMENSIONS
• For outdoor unit weights, see pages 8 - 9.
• For clearances, see Figure 42-1.
FIGURE 40-1: OUTDOOR ENCLOSURE MOUNTED FLUSH FIGURE 40-2: OUTDOOR ENCLOSURE MOUNTED ON A CURB
OM-8087 OM-8088
OM-8089
B
A
C
A
B
14" - 36" in
(356 - 914 mm)
2" (51 mm)
increments
Remove
bottom
bracket
for wall
mounting
Wall mount
brackets
(each side)
FIGURE 40-3: OUTDOOR ENCLOSURE WALL MOUNTED
D
E
Steam outlet
N
M
