RTS HUMIDIFIER RX SERIES INSTALLATION, OPERATION, AND MAINTENANCE MANUAL
Heaters
REPLACEMENT PARTS
Table 67-1:
RTS heaters (continued)
RTS
model
Maximum
steam capacity
Power
Heater quantity and part number
Single-phase Three-phase
lbs/hr kg/h kW 120V 208V 240V 277V 480V 600V 208V 240V 380V 480V 600V
RX-63-3 63 28.6 21 - 6-008 - - - - - - - - -
RX-75-3 75 34.0 25 - 3-022 3-023 6-017 - - - - - - -
RX-90-3 90 40.8 30 - -
3-009,
3-016
6-017 - -
3-002,
6-008
- - - -
RX-102-3 102 46.3 34 - - - 6-017 - - 9-008 - - -
RX-126-3 126 57.1 42 - - - - - -
6-008,
3-014
6-009,
3-016
- - -
RX-144-3 144 65.3 48 - - - -
3-012,
6-020
-
3-009,
6-016
- - -
RX-162-3 162 73.5 54 - - - - 6-028 - - 9-016 -
RX-189-3 189 85.7 63 - - - -
3-012,
6-028
3-013,
6-030
- -
6-018,
3-024
6-020,
3-028
6-021,
3-030
RX-216-3 216 98.0 72 - - - - -
3-021,
6-030
- -
3-018,
6-024
3-020,
6-028
3-021,
6-030
RX-243-3 243 110.2 81 - - - - - 9-030 - - 9-024 9-028 9-030
RX-102-4 102 46.3 34 - 4-022 4-023 - - - - - - - -
RX-126-4 126 57.1 42 - -
4-003,
4-023
8-017 - - - - - - -
RX-144-4 144 65.3 48 - - - 8-017 - - 12 -008 - - - -
RX-162-4 162 73.5 54 - - - - - -
8-008,
4-014
-- - - -
RX-216-4 216 98.0 72 - - - - 8-028 - - 12-016 - - -
RX-264-4 264 119.7 88 - - - -
4-012,
8-028
4-013,
8-030
- -
4-010,
8-024
4-012,
8-028
4-013,
8-030
RX-288-4 288 130.6 96 - - - - -
4-021,
8-030
- -
4-018,
8-024
4-020,
8-028
4-021,
8-030
RX-324-4 324 146.9 108 - - - - - 12-030 - - 12-024 12-028 12-030
Notes:
All RTS models operate at 50/60 Hz.
600931 are the first digits of the heater part number.
