RTS HUMIDIFIER RX SERIES INSTALLATION, OPERATION, AND MAINTENANCE MANUAL
Subpanel for -1 and -2 models
REPLACEMENT PARTS
Table 69-1:
RTS humidifier replacements parts
No. Description Qty. Part No.
1 MAIN CONTROLLER VL6 1 183504-014
2
TERMINAL BLOCK 3 POLE PRESSURE CONTACT 1 408300-002
BLOCK POWER 115A 600V MARATHON 3 POLE 1 407603
3
CONTACTOR 40 AMP SIEMENS 3RT-23 1 407010-202
CONTACTOR 50 AMP SIEMENS 3RT-27 1 407010-203
4
TRANSFORMER, 120V, 24V SEC - QC 1 408965-101
TRANSFORMER, 208/240/480V, 24V SEC - QC 1 408965-102
TRANSFORMER, 230/400, 24V SEC - QC 1 408985-101
TRANSFORMER, 380/440V, 24V SEC - QC 1 408985-102
TRANSFORMER, 277V, 24V SEC - QC 1 408982-101
TRANSFORMER, 600V, 24V SEC - QC 1 408986-101
5 FAN COOLING 24" LEADS VM99 1 408677-001
6 HARNESS POWER CABLE RTS 1 600912-XXX
7 HEAT SINK SSR CARLO GAVAZZI ALUMN 1 600914
8 SSR CARLO GAVAZZI RGS1A60D50KKE 50A 1 600913
9
FUSE 10A 600V ATM MIDGET (-2 models) 1 406700-010
FUSE 15A 600V ATM MIDGET (-2 models) 1 406700-015
FUSE 20A 600V ATM MIDGET (-2 models) 1 406700-020
FUSE 25A 600V ATM MIDGET (-2 models) 1 406700-025
FUSE 30A 600V ATM MIDGET (-2 models) 1 406700-030
FUSE 35A 480V AG (-2 models) 1 406720-035
FUSE 40A 480V AG (-2 models) 1 406720-040
FUSE 45A 480V AG (-2 models) 1 406720-045
FUSE 50A 480V AG (-2 models) 1 406720-050
FUSE 60A 480V AG (-2 models) 1 406720-060
FUSE 35A 600V CF UL/CSA (-2 models) 1 406756-006
FUSE 40A 600V CF UL/CSA (-2 models) 1 406756-007
FUSE 45A 600V CF UL/CSA (-2 models) 1 406756-008
FUSE 50A 600V CF UL/CSA (-2 models) 1 406756-009
FUSE 60A 600V CF UL/CSA (-2 models) 1 406756-010
10
HOLDER FUSE 3 POLE KTK-MIDGE (-2 models) 1 407450-001
BLOCK FUSE 40608G GOULD (-2 models) 1 407500
FUSE HOLDER 60A 1 POLE CF CLASS (-2 models) 1 406751-001
11 HOLDER FUSE 2 POLE MIDGET - ENCLOSED 1 407450-005
12 FUSE 4 AMP 600 VOLT ATM 1 406740-015
* Specify humidifier model and serial numbers when ordering.
