XT SERIES
Electrode Steam Humidifiers
STEAM HUMIDIFICATION
Installation, Operation, and
Maintenance Manual
Read and save these instructions

Table of Contents

Questions and Answers

  • E
    Emily GarciaAug 19, 2025
    Why is water constantly running down the drain of my DriSteem XT?
    • C
      colemanjeffreyAug 19, 2025
      If the DriSteem Humidifier is constantly running water down the drain, it could be due to: * **Malfunctioning Drain Valve:** Use the Test Mode to check the valve's function. * **Debris in Drain Valve:** Remove the cylinder and clean any debris from the drain valve that may be preventing it from closing properly. * **O-ring Issues:** Take out the cylinder and make sure the O-ring in the drain valve is correctly seated in its groove. * **Fill Cup Overflow:** Inspect the internal hoses for any kinks or blockages that might be causing water to flow from the fill cup overflow port.
  • C
    Cheryl JordanAug 22, 2025
    What to do if my DriSteem XT is leaking water?
    • L
      Lindsey JacksonAug 22, 2025
      If your DriSteem Humidifier is leaking water, inspect the following: * **Plumbing Connections:** Check the supply water connection at the fill valve inlet and tighten if necessary. Inspect internal hose clamp connections, repositioning and tightening clamps as needed. Also, check the steam hose connection on top of the cylinder and tighten the clamp if needed.
  • L
    Luke MiddletonAug 25, 2025
    Why DriSteem XT will not fill?
    • J
      Jennifer GillAug 26, 2025
      If your DriSteem Humidifier will not fill, check the following: * **Water Supply Valve:** Ensure that the field-installed supply water shut-off valve is fully open. * **Fill Valve Function:** Use the Test mode to check the fill valve's operation.
  • B
    Barbara KirbyAug 28, 2025
    What to do if my DriSteem Humidifier will not drain?
    • D
      dawnsotoAug 28, 2025
      If your DriSteem Humidifier will not drain, consider the following: * **Debris in Drain Valve:** Remove the cylinder and thoroughly clean any debris from the drain valve that might be obstructing the outlet port. * **Drain Valve Function:** Use the Test mode to check the drain valve's operation.
  • R
    Rebecca BondAug 31, 2025
    Why does my DriSteem Humidifier make a gurgling sound?
    • M
      Matthew SmithAug 31, 2025
      If the DriSteem Humidifier is making a gurgling sound, it is likely due to excess condensate in the steam hose. To resolve this, ensure the steam hose has a consistent downward slope either back to the humidifier or towards tees and traps located in the low spots of the hose.
  • S
    Steven BrownSep 3, 2025
    Why is my DriSteem XT not satisfying demand?
    • G
      Grace PruittSep 3, 2025
      If your DriSteem Humidifier is not satisfying the demand, there are a couple of things to check: * **Control Setting:** The control setting may be too low. Adjust the control to a higher setting. * **Control Location:** The control might be mounted in the wrong location. Refer to the installation instructions included with the control for the correct mounting location.
  • J
    Joseph JohnsonSep 6, 2025
    How to decrease excess humidity from DriSteem Humidifier?
    • K
      kimberly46Sep 6, 2025
      If there is excess humidity when using your DriSteem Humidifier, consider the following: * **Control Setting:** The control setting may be too high. Adjust the control to a lower setting. * **Control Location:** The control might be mounted in the wrong location. Refer to the installation instructions included with the control for the correct mounting location.
  • B
    Bryan SnyderSep 9, 2025
    Why fill valve of DriSteem XT makes banging sound?
    • M
      mcdanielstephenSep 9, 2025
      If the fill valve on your DriSteem Humidifier is making a banging sound, this is likely due to water hammer from line pressure. Here are a few solutions: * Ensure the water supply line is not in contact with any ductwork. * Install a shock arrestor. * Install a section of 1/4" braided fill line, ensuring it conforms to all governing codes.
  • J
    John HendersonSep 12, 2025
    What causes water in duct from dispersion tube of DriSteem XT Humidifier?
    • J
      Jennifer OlsonSep 12, 2025
      If you notice water in the duct coming from the dispersion tube of your DriSteem Humidifier, it could be due to: * **Incorrect Installation:** Make sure the dispersion tube is installed with the tubelets facing straight up. * **Impurities:** Rinse the cylinder and hose in clean water to remove any impurities in the steam hose or tubing that may be causing foaming.
  • S
    Samantha PruittNov 15, 2025
    How to fix DriSteem XT that will not turn on?
    • B
      brownfrankNov 15, 2025
      If your DriSteem Humidifier won't turn on, there are several potential causes to investigate: * **Power Issues:** Ensure the main power supply and switch are functioning. Verify the correct voltage across the L1 and N/L2 terminals. * **Safety Interlock:** Make sure the front cover is securely attached to engage the safety interlock switch, and then press the On/Off button. * **Wiring:** Check the L1, N/L2, and Ground connections. Also, check the wiring and settings on accessory items like the high limit switch and airflow proving switch. * **Internal Connections:** Follow the shutdown procedure, then ensure the electrode and high water probe connections on top of the cylinder are secure. Confirm the ribbon cable from the membrane switch is firmly plugged into the control circuit b...

Summary

Warnings and Cautions

General Safety Precautions

Documented safety alerts and general warnings for user safety.

System Hazards

Details hazards related to electrical shock, hot surfaces, and water.

Piping Safety

Focuses on safe practices for drain piping and water pressure management.

Overview and Specifications

Product Description and Water Needs

Introduces the humidifier, its components, and water requirements.

Technical Specifications

Includes dimensions, capacities, and dispersion options.

Installation

Site Preparation and Mounting

Guides on location, clearances, and mounting the unit.

Piping, Wiring, and Components

Covers cylinder, fill cup, piping, and wiring.

Dispersion and Specialized Systems

Covers dispersion, steam blowers, and outdoor enclosures.

Operation

Principle of Operation

Explains the core working mechanism of the XT Series humidifier.

Start-up Procedures

Outlines the essential steps for system start-up and initial operation.

Maintenance

Shutdown and Cylinder Service

Describes safe shutdown and steam cylinder replacement.

Drain Valve Maintenance

Provides instructions for servicing the drain valve assembly.

Troubleshooting

Model XTP Troubleshooting Guide

Offers guidance on diagnosing and resolving common issues.

Replacement Parts and Accessories

Humidifier and Enclosure Parts

Lists replacement parts for indoor units and outdoor enclosures.

Blower Parts and Accessories

Details replacement parts for XT steam blowers and accessories.

DriSteem XT Series Specifications

General IconGeneral
Construction MaterialStainless steel
Voltage208V, 240V, 480V, 600V
Phase3-phase
Steam Output ControlModulating
Water Connection1/2" NPT
Drain Connection1/2" NPT
Steam Distribution Optionsdispersion tube
TypeSteam humidifier
